Appendix a, Bms ii menus – AERCO BMS II BOILER User Manual
Page 69

APPENDIX A
A-3
APPENDIX A
_____________________________
BMS II MENUS
- Continued
AVAILABLE CHOICES OR LIMITS
MENU LEVEL & OPTION
MINIMUM
MAXIMUM
DEFAULT
FIELD ADJUST MENU – Cont.
OFFSET ENABLE
OFF,
ON
OFF
SUN
OFFS TEMP
-50.0°F
50.0°F
00.0
SUN ON HOUR
00
23
00
SUN ON MINUTE
00
59
00
SUN OFF HOUR
00
23
00
SUN OFF MINUTE
00
59
00
Etc., Up To:
SAT OFF MINUTE
00
59
00
CONFIGURATION MENU
BOILER OP MODE
SEQUENTIAL MODE,
PARALLEL MODE
SEQUENTIAL
MODE
SYS INTLK CONFIG
START ENABLED,
ALWAYS ENABLED
START ENABLED
BLR START LEVEL
001%
100%
020%
BLR STOP LEVEL
001%
040%
016%
MAX POWER INPUT
050%
100%
100%
FAIL SAFE MODE
SHUTDOWN,
CONSTANT SETPOINT
SHUTDOWN
TUNING MENU
PROPORTIONAL BND
005°F
120°F
070°F
INTEGRAL GAIN
0.00 REP/MIN
9.99 REP/MIN
0.15 REP/MIN
DERIVATIVE GAIN
-2.00 MIN.
2.00 MIN.
0.15 MIN.
HDR TEMP DEADBND
001°F
015°F
005°F
