OPERATION
3-16
3.13 BMS II QUICK-START GUIDE
NOTE
The “Quick Start” procedures in paragraph 3.13 assume that the
user fully understands the BMS II menu structure and is able to
navigate through these menus to display and change menu
options. Refer to paragraph 3.3 for menus and menu processing
procedures.
The following procedure assumes that you are programming a new BMS II that has the “Factory Default”
settings currently stored in memory.
If you wish to restore a “Field-Programmed” BMS II to the “Factory Default” values, go to the
CALIBRATION MENU and select the RESET DEFAULTS option. ALL SETTINGS, EXCEPT TIME AND
DATE, WILL RETURN TO THEIR FACTOR DEFAULTS.
This paragraph provides the instructions to quickly start up and operate the BMS II in some of the most
commonly used modes. The ranges and default values of the Menu Options used in the following
instructions are summarized in Appendix A.
CONSTANT SETPT MODE (Default)
MENU & OPTION ACTION
1. SETUP MENU

ENTER PASSWORD Enter 159

2. RS485 MENU Enter this menu if there are more than 2 boilers (default),
otherwise go to step 3

NUMBER NETW BOILERS This setting is preset to 2. If more than 2 Boilers (default), enter
number (03, 04, etc)

NETW BOILER 01
ADDRESS= 001 Address 001 and 002 are preset. Enter other Network Addresses if
required (003, 004, 005, etc.)

3. FIELD ADJUST MENU If Setpt is other than 160°F (default), enter this menu; otherwise go
to step 4

INTERNAL SETPT Enter Setpoint temperature

4. CONFIGURATION MENU If BLR START LEVEL=20% & BLR STOP LEVEL=16%, skip this
menu.

BLR START LEVEL Enter Boiler Start Level Percent (default = 20%). See Appendix I.

BLR STOP LEVEL Enter Boiler Stop Level Percent (default = 16%). See Appendix I.

5. CALIBRATION MENU Required Only For Modulex Installations

LOAD START PCT Enter a Value 2% Below the BLR START LEVEL
