APPENDIX A
A-1
APPENDIX A
_____________________________
BMS II MENUS
AVAILABLE CHOICES OR LIMITS
MENU LEVEL & OPTION MINIMUM MAXIMUM DEFAULT
OPERATING MENU
HEADER TEMP 40 280 N/A
HEADER SET TEMP 40 220 N/A
OUTSIDE AIR TEMP -60 180 N/A
PERCENT OF LOAD 0 100 N/A
I/O STATUS Bit 0 = AUX Relay
Bit 1 = Fault Relay
Bit 2 = Sys Start Relay
Bit 3 = Empty
Bit 4 = Setback
Bit 5 = Interlock 2
Bit 6 = Interlock 1
Bit 7 = Empty
RETURN TEMP 40 280 N/A
SETUP MENU
ENTER PASSWORD
(Level 1 = 159)
(Level 2 = 6817)
0 32000 0
SET MONTH 01 12
SET DATE 01 31
SET YEAR 00 99
SET HOUR 00 23
SET MINUTE 00 59
SET DAY OF WEEK SUNDAY TO SATURDAY
RS232 MENU
RS232 MODE MODBUS SLAVE,
NORMAL
MODBUS SLAVE
RS232 BAUDRATE 2400, 4800,
9600, 19200
9600
MODBUS ADDRESS 128 247 128
NETWORK TIMEOUT (Seconds) 005 240 060
MODBUS PASS THRU DISABLED,
ENABLED
DISABLED
