AERCO BMS II BOILER - Manual (Page 33)

OPERATION
3-1
CHAPTER 3 - OPERATION
3.1 INTRODUCTION
The information in this Chapter provides a guide to the operation of the BMS II using the controls and
display mounted on the front panel of the unit. This Chapter describes the basic procedure to navigate
through the extensive array of menus and options incorporated in the BMS II design. Descriptions for all
menus and options are also provided.
3.2 FRONT PANEL OPERATING CONTROLS AND DISPLAYS
The front panel of the BMS II contains an vacuum fluorescent display (VFD) and an 8-key touch-pad. The
display and controls are illustrated and described in Figure 3-1 and Table 3-1 respectively.
Figure 3-1. BMS II Front Panel Controls and Displays
