KEYENCE SL-R11E - Manual (Page 20)

Chapter 2 Functions
2-8
2
English ENGLISH
2-13 Input/Output Terminal Circuit
OSSD1,2 output circuit
OSSD
(PNP)
control
circuit OSSD
monitor
circuit
OSSD1,2
0V
2.2k
+24V
1,2
9
AUX PNP output circuit
AUX
(PNP)
control
circuit
AUX(PNP)
(50mA max.)
0V
+24V
4
9
AUX NPN output circuit
AUX
(NPN)
control
circuit
AUX(NPN)
(50mA max.)
0V
5
9
Power OFF input circuit
Internal
circuit
24V
Power OFF input
8
6
9
0V
