APPENDIX A -- USER INTERFACE MENUS (CON’T)
Configuration Menus
BACview MENU POINT NAME
BACnet
OBJECT
RANGE DEFAULT FIELD ASSISTANT MENU
HOME Select function below Properties/Equipment
CONFIG CONFIGURATION Configuration
SETPOINT SETPOINTS Setpoints
Occupied Heating Setpoint occ_ht_stpt 40---90 ° F 70
Occupied Cooling Setpoint occ_cl_stpt 55---99 ° F 74
Unoccupied Heating Setpoint unocc_ht_stpt 40---90 ° F 55
Unoccupied Cooling Setpoint unocc_cl_stpt 55---99 ° F 90
Effective Cool Setpoint eff_cl_stpt xx ° F
Effective Heat Setpoint eff_ht_stpt xx ° F
Optimal Start optm_start 0---4 hr 4
Occ Relative Humidity Setpoint occ_dehum_stpt 0---unocc set-
point %rh
60
Unocc Relative Humidity Set-
point
unocc_de-
hum_stpt
30---100 %rh 95
DCV Max Ctrl Setpoint iaq_stpt_max 0---9999 ppm 650
Power Exhaust Setpoint pexh_stpt 20---90 %Open 50
Sched Weekly schedule MON---SUN none (BACview Only)
Exceptions none
ALARMS ALARM CONFIGURATION Alarm Configuration
SPACE TEMPERATURE ALARM
Occupied Alarm Hysteresis occ_spt_alrm_hys
t
2---20° F 3
Alarm Delay (min/deg) spt_alrm_delay 0---30 minutes 10
Unoccupied Low SPT Alarm
Limit
uno_spt_alrm_lo_l
mt
35---90 ° F 45
Unoccupied High SPT Alarm
Limit
uno_spt_alrm_hi_l
mt
45---100 ° F 95
SUPPLY AIR TEMPERATURE ALARM
Low SAT Alarm Limit sat_lo_alrm_lim 15---90 ° F 35
High SAT Alarm Limit sat_hi_alrm_lim 90---175 ° F 160
SPACE HUMIDITY ALARM
Low Space Humidity Alarm
Limit
sprh_lo_alrm_lim 0---99 %rh 30
High Space Humidity Alarm
Limit
sprh_hi_alrm_lim 0---99 %rh 70
IAQ / VENTILATION ALARM
Occ High CO2 Alarm Limit
(ppm)
iaq_occ_hi_lmt 0---9999 ppm 1200
