Reference Guide D-3
Writer: Holly Jahangiri Saved by: Alyce Klingler-Castle Saved date: 06/10/97 3:54 PM
Pages: 4 Words: 241 Template: d:\95office\templates\commapp.dot
File Name Appd Part Number 278019-002
Serial Interface
Connector and Icon Pin Signal
1 2 3 4 5
6 7 8 9
1
2
3
4
5
6
7
8
9
Carrier Detect
Receive Data
Transmit Data
Data Term Ready
Ground
Data Set Ready
Request to Send
Clear to Send
Ring Indicator
Universal Serial Bus (USB) Connector
Connector and Icon Pin Signal
1 2 3 4
1
2
3
4
VCC (Cable power)
- Data
+ Data
Ground (Cable
ground)
