Compaq Deskpro 2000 Series User Manual
Page 110
6-10 Upgrading the Minitower Computer
Writer: Holly Jahangiri Saved by: ACastle Saved date: 07/25/97 2:13 PM
Pages: 28 Words: 3072 Template: c:\msoffice\templates\comm.dot
File Name Ch6.doc Part Number 278019-001
4. Slide the expansion board into the expansion slot and press
it firmly into place.
Sliding an Expansion Board into Place in the Expansion riser board
✎
When you install an expansion board, make sure you press firmly
on the board so that the whole connector seats properly in the
expansion board slot.
5. Replace the retaining screw.
6. Replace the riser brace into the minitower.
Replacing the Brace into the Minitower
7. Replace the computer cover.
