Parts List with Part Numbers

TRACKMASTER

8-12

TMX428 Owner’s Manual

July 2014

Deck Assembly


Item

Description

Part Number Qty

1

Frame Assembly TMX428

317-Various

1

2

Belt Running with V-Guide

317-160-002

1

3

Bolt HHCS 5/16-18 x .75” Lg

001-1167

6

4

Lock Washer 5/16” Dia

001-1451

7

5

Flat Washer 5/16” Dia

001-1440

9

6

Deck Support Channel Weldment

317-379-001

3

7

Deck Isolator 1.75” Dia with Stud

317-345-003

6

8

Flange Lock Nut HNS 5/16-18

001-1398

6

9

Deck Running Board

317-160-025

1

10

Screw HSFCHCS 5/16”-18 x 1.5” Lg PLTD

001-1739

6

11

Roller Front

317-160-156

1

12

Set Screw 5/16”-18 x 1.75” Lg

317-160-224

1

13

Nut FHNZ 5/16-18 Grade 5

001-1387

1

14

Bolt HSHCS 5/16”-18 x 2” Lg PLTD

001-1748

1

15

Rear Roller

317-160-157

1

16

Belt Tension Plate

317-649-001

2

17

Screw HSHCS 5/16”-18 x 3” Lg PLTD

001-1737

2

18

End Cap LH

317-160-175

1

19

End Cap RH

317-160-176

1

20

Screw HSBHCS 5/16”-18 x 1” Lg PLTD

001-1735

2

21

Extrusion Anti Skid Rubber 60” LG

317-160-055

2
