Parts List with Part Numbers

TRACKMASTER

8-8

TMX428 Owner’s Manual

July 2014


Motor Pan Assembly Wiring


Item

Description

Part Number Qty

1

Screw HHWTS #8-32 x .375 Lg

001-1744

4

2

Clamp Plastic ¼” ID

317-160-227

4

3

Harness 110V DC Treadmill
Harness 220V DC Treadmill

317-160-261
317-160-262

1

4

Harness Resistor

417-160-026

1

5

Speed Sensor

317-160-034

1

6

Harness Elevation

317-160-231

1

7

HH Screw #10-32 x .375 Lg GRD

317-160-076

2

8

Harness Motor Controller

417-160-031

1

9

Harness Ground

317-160-070

2

10

Harness Main DC Treadmill

317-160-247

1

11

Harness Jumper

317-160-071

2

12

LW #10 EXT Tooth

001-1751

1

13

Surge Suppressor

317-160-129

1

14

Decal ground

317-160-273

1

15

Cable RS232 Panel Mount

317-160-236

1

16

Cable USB Panel to USB B

317-160-237

1

17

Plate RS232 & USB

317-160-254

1

18

HHCS #8-32 x .50 Lg

001-1764

2

19

HNS #8-32 Flange Nut

001-1636

2

20

Decal Caution

317-160-274

2

21

Zip Tie 8” Lg

317-160-280

1

22

Zip Tie 4” Lg

317-160-075

1

23

RMHS #4-40 x .375 Lg

001-2360

2
