Page 52
Parts List with Part Numbers
TRACKMASTER
8-6
TMX428 Owner’s Manual
July 2014
Motor Pan Assembly Wiring
DC MOTOR ASSEMBLY
DC DRIVE MOTOR
CONNECTOR PE,W,V,U
DC DRIVE MOTOR
FEEDBACK CONNECTOR
115V CONFIGURATION 220V CONFIGURATION
RESITOR OMITE
DRIVE DC SERVO PC2303-012-N
BLACK (110-120)
BLANK
BROWN (HOT)
BLANK
BLANK
BLACK (208-240)
BROWN (HOT)
BLANK
WHITE (COMMON)
RED (INCLINE UP)
BLACK (INCLINE DOWN)
CONNET COLOR CONFIGURATION
.060 GAP
CONNECT 2 PIN CONECTOR
BROWN WIRE ON TOP
ORANGE WIRE ON TOP
ITEM 12 SHEET 1 OF 2
CIRCUIT BOARD ASSEMBLY
MULTIPLE GROUND
CONNECTION
DC FAN WIRE RED
DC FAN WIRE BLACK
