CardioPerfect Workstation
SpiroPerfect Module
– User Manual
DIR 80012334 Ver. F 63 / 95
11.2 Print Report Formats
The SpiroPerfect module prints the following report formats:
All plus best effort FVC
Best FVC
Best MVV
Best SVC
Best Three FVC
Measurements MVV
Measurements SVC
Measurements FVC
Social Security
Trend
Each format contains the patient’s personal information, test information, interpretation,
parameter table and all but the measurement report contain a graphs section.
Please refer to the Workstation manual for further information on printing a test.
11.3 Print Preview
To Preview a Test

Select File > Print Preview. The print dialog box appears. See Figure 11.1.

Select type of report to preview.
The name of the report type appears at the top of the dialog box.
The print preview window appears.
Figure 11.2 Print preview dialog box
Name of the report type
