CardioPerfect Workstation
SpiroPerfect Module
– User Manual
DIR 80012334 Ver. F 16 / 95
3 Installing the SpiroPerfect Spirometer
The SpiroPerfect Spirometer consists of two elements: the spirometry sensor, and the
software that runs on the computer to which the sensor is connected. Before you can start
recording spirometry tests, you need to:

Connect the sensor to the computer.
CAUTION Always use the USB extension cable. The USB extension cable
prevents damage to the spirometer.

Configure the software.
Warm up the Spirometer
After connecting the device it is recommended to let the Spirometer warm up.
1. Connect the Spirometer to the computer.
2. Open the Spiro module.
The sensor starts to warm up as soon as the SpiroPerfect module is opened.
3. Wait for at least 5 minutes before starting a new test.
Flow sensor with USB connection:
SpiroPerfect from Welch Allyn
OEM SpiroPerfect manufactured by Medikro Oy, Finland for Welch Allyn Inc, USA.
0537
For information on connecting the Flow sensor with USB connection see section 3
Installing the SpiroPerfect Spirometer.
