The Measurements Tab contains a number of parameter values for each FVC, SVC and MVV
efforts. Each effort is represented by a separate column.

The measurement table only displays the efforts belonging to the selected stage. It only
lists the parameters selected in the settings. See page 24 to select parameters for display
in the Measurement table.

Information on test reproducibility is displayed in the reproducibility table that is placed
below the Measurements Table. In particular, the FVC and FEV1 absolute value variance
(difference) between the best effort and the second best effort is analyzed for both pre
and post tests.

When a value is in bold red text , that value is below the lower prediction limit.
9.11 Compare Tests
With SpiroPerfect, you can compare final results from different tests recorded for the same
patient.
Selecting various tests
1. Choose Action
2. Select Comparison
The following screen appears
Figure 9.16 Comparison dialog box
Click on the check box in front of each test to select tests. The best pre and best post efforts
of the patient’s selected tests are compared.
Available views are:

FVC

Measurements

Trend
The trend view displays a graphical overview of the patient’s performance over time.
