136 Technical data Welch Allyn 1500 Patient Monitor
Capnography
Module Mini Medi CO
2
Measuring method Non dispersive Infrared Spectroscopy
CO
2
units mmHg or kPa
CO
2
, etCO
2
, fiCO
2
, range 0 to 99 mmHg (CO
2
[mmHg] / Environment pressure) x 100 = CO
2
[%]
Curve Resolution 0.1 mmHg
etCO
2
, inCO
2
Resolution 1 mmHg
CO
2
Accuracy 0 to 38 mmHg: ± 2 mmHg
39 to 99 mmHg: ± 5 % of reading and 0.08 % for every 1 mmHg above 38
mmHg
Respiration Rate range 0 to 150 Resp/min
Respiration Rate
Accuracy 0 to 70: ± 1 Resp/min
71 to 120: ± 2 Resp/min
121 to 150: ± 3 Resp/min
Flow rate 50 ml/min, (42.5 < flow < 65) flow measured by volume
Waveform sampling 20 samples/s
Initialization Time 40 s (typical)
System Response Time 5.6 s (typical combined response time)
Calibration Interval Initially calibrate after 1,200 operating hours, then once a year or
after 4,000 operating hours, whichever comes first. The initial
calibration should not occur before 720 hours of use. If the initial
calibration is done before 720 hours of use, the module will reset
to require its next calibration after 1200 hours, instead of after
4000 hours.
Note The capnography component of this product is covered by one or more of the following US patents:
6,428,483; 6,997,880; 5,300,859; 6,437,316; 7,488,229; 7,726,954 and their foreign equivalents.
Additional patent applications pending.
