72 RL-TS Series Operation Manual
* -
If headed with no data, the numeric value is headed by 0 (30H) by factory default setting. Using the
function setting, it can be headed by “SP” (20H).
-When expression units are changed or switched to display of parts counting, percentage weighing, or
unit converting, the decimal place is changed (Refer to “ Sample communication formats” (P. 70)).
[U1, U2] (two characters)
Indicates the unit used to show numeric data.
U1 U2 Code Meaning Balance indicator
(SP) G 20H 47H gram g
K G 4BH 47H Kilogram kg
C T 43H 54H carat CT
O Z 4FH 5AH ounce
L B 4CH 42H pound
O T 4FH 54H troy ounce
D W 44H 57H pennyweight
G R 4BH 52H Grain Bottom right grain
T L 54H 4CH tael (Hong Kong)
T L 54H 4CH tael (Singapore, Malaysia) Top right
T L 54H 4CH tael (Taiwan) Middle right
M O 4DH 4FH momme mom
t o 74H 6FH tola
P C 50H 43H Pieces Pcs
(SP) % 20H 25H Percentage %
(SP) # 20H 23H Computation results, numbers, etc. #
[S1] (one character)
Indicates the judgment result when the limit function is used.
S1 Code Description Remarks
L 4CH Below (LO) 1- or 2-point scale
G 47H Appropriate (OK)
H 48H Above (HI)
T 54H Cumulative value Data type
U 55H Unit weight
(SP) 20H No judgment result or no data type specified
d 64H Gross
