RL-TS Series Operation Manual 71
77B
 Data format
- 6-digit numeric format
Consists of 14 characters including terminators (CR = 0DH/LF = 0AH).
1 2 3 4 5 6 7 8 9 10 11 12 13 14
P1 D1 D2 D3 D4 D5 D6 D7 U1 U2 S1 S2 CR LF
- 7-digit numeric format
Consists of 15 characters including terminators (CR = 0DH/LF = 0AH). A parity bit can be
appended.
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
P1 D1 D2 D3 D4 D5 D6 D7 D8 U1 U2 S1 S2 CR LF
- Extended 7-digit numeric format
This is an extended version of the 7-digit numeric format and is different from the 7-digit numeric
format in that:
- the data length can be seven bits rather than eight bits, and
- the stop bit length can be one bit rather than two bits.
- If you select Japanese (katakana) for printed language, the data length is automatically set to eight
bits.
B
 Meanings of data
[P1] (one character)
Indicates the polarity of data.
P1 Code Description
+ 2BH Zero or positive data
- 2DH Negative data
[D1 to D7 (or D8)] (seven or eight characters)
Numeric data is stored.
D1~D7(D8) Code Description
0~9 30H~39H 0 to 9 (numeric)
⋅ 2EH
- Decimal point (floating)
- Omitted when numeric data does not contain decimal places. In this case, a
space is output to the least significant digit.
SP (Space) 20H
- A space heading a numeric value
- When numeric data does not contain decimal places, a space rather than a
decimal point is output to the least significant digit.
