LOSB9516 Xcelorin Electronic Speed Control v1.0 Page 16
Connect the Xcelorin ESC and Sensorless Motor
There are three wires from the ESC a black, blue and white for the motor.
Each wire will be soldered to a single motor tab. Make certain there is not a
short across any of the motor connections. If shorted together, you will
damage the ESC when the batteries are connected.
If the motor you are using runs backwards after installation, you can correct
this in one of two ways:
• Switch any two motor wires on the ESC.
• Using the ESC Software, you can select the Reverse Rotation feature.
