Losi LOSA99171 - Manual

Operating Instructions
Temp-Tuner
Infrared thermometer with tuning screwdriver
HOW TO INSTALL BATTERY AND SCREWDRIVER:
Install the two LR44 batteries with the “+” pointing out. Install the
“Battery Cover” making sure it is level. Use a screwdriver to
carefully turn it clockwise (to the right) to tighten it.
Install the screwdriver fixture into the body aligning the small and
large holes with the similar large and small holes on the temp
probe body. Install the black Allen head cap screw into the larger
hole and thread it into the opposite side of the body. Use an Allen
wrench to tighten.
BATTERY REPLACEMENT
：
When the “Battery icon” flashes in the LCD, the batteries are low
and need to be replaced. With the readout OFF, remove the black
Allen bolt that secures the screwdriver and remove the
screwdriver from the body. Remove the battery cover by turning it
counterclockwise (to the left) and remove the two batteries.
Follow the instructions under “How to Install Battery and
Screwdriver” above using fresh batteries.
See WWW.LOSI.COM for warranty information
SPECIFICATION
：
Measurement
Temperature
-33~220
℃（-27.4~428℉）
Operating Temperature 0~50℃（32~122℉）
Storage Temperature -20~65℃（-4~149℉）
Accuracy
±2.5% of reading or 2.5
℃ whichever is greater
Resolution
0.2
℃/0.5℉
Response Time 1sec
Field of View 1:1 optics ratio
Emissive 0.95 fixed
Auto Switching-off 15sec
USING THE TEMP-TUNER
：
Remove the protective metal cap from the temp probe end of the
unit. Install the tapered rubber tip onto the end of the probe.
Place the temp probe into the head opening allowing the rubber
tip to locate it. It should be as straight as possible with the sensor
aiming directly at the glow plug. The tapered rubber tip will
automatically position the probe in the same location every time
you use it. Press the measurement button next to the LCD display
for a second and release to display the surface temperature. Use
the tuning screwdriver to make adjustments as necessary.
℃ OR ℉：
The temperature readout can be changed to ‘
℃’ or ’℉’ by
pressing lightly in the hole on the opposite side of the readout
with a paperclip or small screw driver while the readout is on.
Tuning Tips:
Never run your engine lean or allow it to overheat. You need to
learn at what temperature your engine runs reliably and use the
Temp-Tuner as a reference tool to keep it there following the
manufactures tuning directions.
