LOSB0882

LED Light Set for Mini Desert Buggy

1.

Remove body panels and aluminum roof panel from the vehicle to prepare for light kit installation.

2.

Carefully insert the 4 white LEDs into the two buckets in the front bumper and 2 side buckets on the cage.

Insert the red LED into the rear light bucket located on the rear cage.

3.

Plug the lead from the light module into the AUX port on the Receiver. Should you need the AUX port for

something in the future, simply plug into the open connector provided on the Light Module.

4.

Using double-sided tape (included), mount the LED Light Module in front of the ESC and Receiver on the

battery hold down.

5.

Replace body panels and aluminum roof panel on vehicle.

6.

With charged battery installed in vehicle, turn on the transmitter, then turn Light Module switch to ON

position. Turn ESC power switch to ON position and the lights will automatically illuminate. When finished

running the vehicle, switch ESC to OFF and lights will turn off automatically.

Insert white LEDs into front light buckets.

Insert white LEDs into side cage light

buckets.

Insert red LEDs into rear light buckets.

Plug the lead from the light module into the AUX port on the

Receiver. Using double-sided tape (included), mount the LED

Light Module in front of the ESC and Receiver on the battery

hold down.

800-0419

Printed in China 12/09
