Losi LOSB9556 1/8 Xcelorin ESC Manual - Manual (Page 14)

LOSB9516 Xcelorin Electronic Speed Control v1.0 Page 14
Setup/Calibration to Transmitter
To perform the setup/calibration between the ESC and Transmitter follow these
steps:
1. Turn on the transmitter.
2. While turning on the vehicle Press and Hold the setup button, notice the
Yellow LED is now ON solid. When the Yellow LED is on solid, you can release
the setup button.
Note: If you cannot get the ESC to Calibrate, you may need to reverse your
Throttle Servo on the transmitter.
3. Using the throttle trigger pull Full Throttle until the Green LED is ON solid.
4. Next push the throttle trigger to Full Brake until the Red LED is ON solid.
5. Now return the throttle trigger to the Neutral position and the Blue LED will
be ON solid.
