Step b, Step b-01 q, Step b-02 q – Losi LOSA0805 User Manual
Page 8: Step b-03 q, Ring gear assembly, Diff case assembly, Complete diff assembly
3
STEP B
Ring Gear Assembly
STEP B-01
q
Diff Case Assembly
STEP B-02
q
Complete Diff Assembly
STEP B-03
q
1
2
3
4
2.5 x 12.80mm
A3503
x 1
Solid
F 8x14x4mm
A6948
x 1
F 8x14x4mm
A6948
x 1
1
1
2
3
4
2
3
2.5 x 12.80mm
A3503
x 1
Solid
4
3x12mm
A3500
x 4
6x11x0.2mm
A3501
x 2
6x11x0.2mm
A3501
x 2
Fill with 7000 wt oil just above the
planetary gear
Tighten the diff screws
in this order
A3505
O-ring
A3511
Ring Gear
A3505
Diff Seal
A3502
Planetary Gear
Axle
A3502
Planetary Gear
A3502
Sun Gear
A3503
Outdrive Cup
A3503
Outdrive Cup
A3500
Diff Housing
A3505
O-ring
A3502
Sun Gear
