1
Steering Link Assembly STEP A-01 q Servo Saver Assembly STEP A-02 q
Fuel Tank/Chassis Brace Assembly STEP A-03 q
STEP A
73.70
LOSI-LOK
LOSI-LOK
LOSI-LOK
L 4-40 x 3/16"
A6306
x 1
4-40 x 1/2"
A6256
x 1
L 4-40 x 3/16"
A6306
x 1
4-40 x 1/2"
A6256
x 1
5-40 x 1/2"
A6721
x 6
L 5-40 x 1/4"
A6302
x 3
4-40 x 1/2"
A6204
x 2
#4 x .030"
A6350
x 2
5-40 x 7/8"
A6537
x 1
Maintenance Tip
4-40 x 4mm
A6253
x 4
A9168
Steering Servo Arm
A9158
Fuel Tank
A4413
Front Chassis
Support
A4408
Steering Post
A4424
Tank Mount
A4405
Chassis
A4407
Servo Saver Tube
A4412
Steering Rack
A4406
Steering
Bellcrank R
A4423
Servo Saver Spring
A4423
Servo Saver Nut
A4406
Steering Bellcrank L
A4412
Drag Link Screw
A4406
Steering Arm
A6044
Rod End Ball
A6044
Rod End
Tighten the Servo Saver
nut all the way down and then
back it off 2 1/2 turns.
