Step f, Step f-01 q, Step f-02 q – Losi LOSA0805 User Manual
Page 27
22
Chassis Guard Installation
STEP F-01
q
Switch Installation
STEP F-02
q
STEP F
Optional Blank Switch Mount Plate
If not using a switch, install the optional
Blank Switch Mount Plate in place of the
Switch Plate.
Supplied with
switch
(not included)
5-40 x 3/8"
A6270
x 7
4-40 x 3/8"
A6206
x 3
A4421
Radio Tray
A4421
Switch Cover
A4421
Switch Mount
A4421
Blank Switch
Plate
A4438
Chassis Guard
A4438
Chassis Guard
