Step f, Step f-03 q, Step f-04 q – Losi LOSA0805 User Manual
Page 28
23
Servo Chart/Wiring Diagram
STEP F-03
q
Throttle Servo Installation
STEP F-04
q
STEP F
Servo Manufacturer, Make/Model
Servo
Spacer
Servo
Horn
JR
All (DZ9100T/S Needs Spacer)
No
23T
A
ir
tr
onics
San
w
a
94357Z, 94358Z, 94649Z, 94360Z,
94452Z, 94758Z, 94737Z, 94738Z
Yes
23T
94102Z, 94112Z
Yes
H
it
ec
All
No
24T
Futaba
All (S9102 DOES NOT FIT)
No
25T
KO
PR
OPO
PDS-2123, 2344, 2363, 2365, 2366
No
23T
No
Airtronics® is a registered mark of Sanwa Electronic Instrument Co., Ltd., Osaka, Japan.
Futaba is a registered trademark of Futaba Denshi Kogyo Kabushiki Kaisha Corporation of Japan
KO PROPO® is a registered trademark of Kondo Kagaku Co., Ltd., Tokyo, Japan.
See Table #2
4-40 x 1/2"
A6204
x 4
#4 x .030"
A6350
x 4
Steering
Servo Wires
Throttle
Servo
Wires
Switch
Wires
A9168
Horn Insert
A4453
Servo Spacer
A4421
Servo Mounting Backplate
Table2: Servo assembly and installation
