5.1.7.1
Set LAN Configuration sub-menu
5.1.7.1.1
IP Address sub-menu
Feature
Options
Description
Setup Help
Channel Number
Each interface has a channel number that is
used when configuring the channel and for
routing messages between channels.
The channel number assignments are
described in IPMI Specification 1.5, table 6-1.
Enter Channel Number
for SET LAN Config
Command.
Proper value below 16.
Channel Number Status
Valid or Invalid
Display Valid if IPMC support LAN Channel.
N/A, display only.
IP Address
N/A
Press Enter to go to sub screen "IP Address".
Enter for IP Address
Configuration.
MAC Address
N/A
Press Enter to go to sub screen "MAC Address".
Enter for MAC Address
Configuration.
Subnet Mask
N/A
Press Enter to go to sub screen "Subnet Mask".
Enter for Subnet Mask
Configuration.
Gateway Address
N/A
Press Enter to go to sub screen "Gateway
Address".
Enter for Gateway
IP Address
Configuration.
Active LAN Channel
Number
None
01
02
Both
Each interface has a channel number that is
used when configuring the channel and for
routing messages between channels.
The channel number assignments are
described in IPMI Specification 1.5, table 6-1.
Enter Active LAN
Channel Number
for Set LAN
Configuration
Command.
Feature
Options
Description
Setup Help
Channel Number
Each interface has a channel number that is
used when configuring the channel and for
routing messages between channels.
The channel number assignments are
described in IPMI Specification 1.5, table 6-1.
Enter Channel Number
for SET LAN Config
Command.
Proper value below 16.
Channel Number Status
Valid or Invalid
Display Valid if IPMC support LAN Channel.
N/A, display only.
IP Address Source
Static
DHCP
Select IP address asource.
Select IP Address
Source:
Static or DHCP
Current IP Address
xxx.xxx.xxx.xxx
Display the current LAN configuration stored
in IPMI NVRAM for IPMI LAN.
N/A, display only.
IP Address
Enter
This allows setting an IP Address for LAN
configuration.
Enter for IP Address
Configuration.
