66 KTC5520/EATX
www.kontron.com
5.1.4.5 Onboard LAN Configuration sub-menu
5.1.4.6 ACPI Configuration sub-menu
5.1.4.6.1 General ACPI Configuration sub-menu
Feature Options Description Setup Help
Onboard LAN 1
Enabled
Disabled
Individually Disable/Enable Onboard 82576
LAN interface.
Enable/Disable LAN
interface.
NOTE: This will not
disable Management
LAN access (KVM).
Option ROM
Enabled
Disabled
Disable/Enable LAN 1 option ROM
Enabled: Initializes LAN
Option ROM.
Disabled: LAN Option
ROM not used.
MAC Display current MAC address of the interface. N/A, display only.
Onboard LAN 2
Enabled
Disabled
Individually Disable/Enable Onboard 82576
LAN interface.
Enable/Disable LAN
interface.
NOTE: This will not
disable Management
LAN access (KVM).
Option ROM
Enabled
Disabled
Disable/Enable LAN 2 option ROM
Enabled: Initializes LAN
Option ROM.
Disabled: LAN Option
ROM not used.
MAC Display current MAC address of the interface. N/A, display only.
Feature Options Description Setup Help
General ACPI
Configuration
N/A
Press Enter to go to sub screen “General ACPI
Configuration”.
General ACPI
Configuration settings
Advanced ACPI
Configuration
N/A
Press Enter to go to sub screen "Advanced ACPI
Configuration".
Advanced ACPI
Configuration settings.
Use this section to
configure additional
ACPI options.
Chipset ACPI
Configuration
N/A
Press Enter to go to sub screen "Chipset ACPI
Configuration".
Chipset ACPI related
Configuration settings.
Feature Options Description Setup Help
Suspend mode
S1 (POS)
S3 (STR)
Auto Select the ACPI state
used for System
Suspend.
Repost Video on S3
Resume
No
Yes
Determines wether to
invoke VGA BIOS post on
S3/STR resume.
