5.1.4.2.2.10 Fifth IDE Slave sub-menu
Feature
Options
Description
Setup Help
Device
Device type
Displays the type of device (Hard Disk, CD-ROM
or ARMD).
N/A, display only.
Vendor
Disk vendor and
description
Displays the device vendor name and/or
model.
N/A, display only.
Size
X KB/MB/GB
Displays system memory size.
N/A, display only.
LBA Mode
Supported
Not Supported
Displays if LBA mode is supported or not by the
device.
N/A, display only.
Block Mode
x Sectors
Displays the Block mode size used by the
device.
N/A, display only.
PIO Mode
0-4
Displays the PIO mode used by the devices.
N/A, display only.
Async DMA
SingleWord or
MutiWord DMA-x
Displays the highest Asynchronous DMA mode
supported by the device.
N/A, display only.
Ultra DMA
x
Displays the highest Synchronous DMA mode
supported by the device.
N/A, display only.
S.M.A.R.T.
Supported or
Not Supported
Displays if S.M.A.R.T. is supported or not by the
device.
N/A, display only.
LBA/Large Mode
Disabled
Auto
LBA (Logical Block Addressing) is a method of
addressing data on a disk drive.
Disabled: Disables LBA
Mode.
Auto: Enables LBA
Mode if the device
supports it and the
device is not already
formatted with LBA
Mode disabled.
Block (Multi-Sector
Transfer) Mode
Disabled
Auto
This option sets the block mode multi sector
transfers option.
Disabled: The Data
transfer from and to
the device occurs one
sector at a time.
Auto: The Data
transfer from and to
the device occurs
multiple sectors at a
time if the device
supports it.
PIO Mode
Auto
0-4
Selects the PIO mode.
Select PIO Mode.
