63 KTC5520/EATX
www.kontron.com
5.1.4.3 SuperIO Configuration sub-menu
DMA Mode
Auto
SWDMA0
SWDMA1
SWDMA2
MWDMA0
MWDMA1
MWDMA2
UDMA0
UDMA1
UDMA2
UDMA3
UDMA4
UDMA5
UDMA6
Selects the DMA mode to access the device.
Single Word DMA [0-2] mode.
Multi Word DMA [0-2] mode.
Ultra DMA [0-6] mode.
Select DMA Mode.
Auto : Auto detected
SWDMAn:
SingleWordDMAn
MWDMAn:
MultiWordDMAn
UDMAn : UltraDMAn
S.M.A.R.T.
Auto
Disabled
Enabled
Self-Monitoring Analysis and Reporting
Technology (SMART) feature can help predict
impending drive failures.
S.M.A.R.T. stands for
Self-Monitoring,
Analysis and Reporting
Technology.
32Bit Data Transfer
Disabled
Enabled
This only affects BIOS accesses to the device.
When enabled, BIOS interrupt 13h will make 32
bits I/Os that the chipset will convert
internally to 2 consecutive 16 bits IOs.
Enable/Disable
32-bit Data
Transfer.
ARMD Emulation Type
Auto
Floppy
Hard Disk
ATAPI Removable Media Device (ARMD) is a
device that uses removable media, such as the
LS120, MO (Magneto-Optical), or Iomega Zip
drives. If you want to boot up from media on an
ARMD, it is required that you emulate boot up
from a floppy or hard disk drive. This is
especially necessary when trying to boot to
DOS. You can select the type of emulation used
if you are booting from such a device.
Select ARMD device
emulation type by BIOS.
Feature Options Description Setup Help
Serial Port1 Address
Disabled
3F8/IRQ4
3E8/IRQ4
2E8/IRQ4
Select the base address used by Serial Port1.
Allows BIOS to Select
Serial Port1 Base
Addresses.
Serial Port2 Address
Disabled
2F8/IRQ3
3E8/IRQ4
2E8/IRQ4
Select the base address used by Serial Port2.
Allows BIOS to Select
Serial Port2 Base
Addresses.
Feature Options Description Setup Help
