25 KTC5520/EATX
www.kontron.com
4.3 Sensor
4.3.1 Reading
This web management section displays all the board sensors readings. The values can be refreshed manually,
if required.
4.4 Control
4.4.1 Remote Power/Reset
This section allows to power down, shutdown, reset and power cycle the board.
Table 4-1: Payload impact
Current POST value is displayed in this page.
4.4.2 Fans
This section allows viewing and controlling the fans speed. Two modes are available to control the fans
"Switch to Manual Speed Control" or "Switch to Auto Temp Control". Click the corresponding button to
switch them. Only the manual mode can be used to modify the memory fan controls. The KTC5520/EATX has
seven fan headers (CPU0 Fan, CPU1 Fan, Mem0 Fan, Mem1 Fan, Sys1 Fan, Sys2 Fan and Sys3 Fan). Their
location can be found in the Quick Reference Sheet and the rating for each fan is: Max 1.5A over 12V (18W).
By default, automatic mode is selected. Targeted temperature, high and low tolerance and maximum and
minimum fan speed need to be set. Fan speed range is from 0 to 63.
The second one is the manual mode and only target speed setting can be adjusted. The lowest value is 0 and
maximum speed is 63.
To activate the new configuration, the button "Set New Speed" must be click.
Command Payload impact
Power Down Now A power down will turn OFF the payload like if the Power button was pushed for 4 seconds.
Graceful Shutdown
A graceful shutdown will power off the payload in a controlled way. It will initiate a proper OS
shutdown.
Reset A reset will immediately reboot the payload like if the Reset button was pushed.
Power Cycle A power cycle will power down and then start the payload.
WARNING
A thermal validation must be done to determine the minimum value required to
safely operate the system in manual mode. If a proper validation can not be done,
the automatic mode should be used.
