70 KTC5520/EATX
www.kontron.com
5.1.4.8.3 South Bridge Configuration sub-menu
5.1.4.9 Virtualization Configuration sub-menu
5.1.4.10 Trusted Computing sub-menu
Feature Options Description Setup Help
HDA Controller
Enabled
Disabled
Enable/Disable intel HDA Audio controller
device.
SMBUS Controller
Enabled
Disabled
Enable/Disable the SMBUS controller.
Restore on AC Power Loss
Power Off
Power On
Last State
Board power state value after AC Power lost.
SATA Master Break Event
Disabled
Enabled
Serial ATA master activity will cause a break
from C3/C6 state if enabled.
Serial ATA master
activity will cause a
break from C3/C6 state if
enabled.
Feature Options Description Setup Help
SR-IOV Supported
Disabled
Enabled
Enable or disable PCI-SIG I/O Virtualization
(IOV).
Intel VT-d
Disabled
Enabled
Enable VT-d feature from INTEL. This will add
DMAR table in ACPI to allows supporting OS to
take advantage of the Virtualization
Technology for Directed I/O.
Feature Options Description Setup Help
TCG/TPM SUPPORT
No
Yes
Enable support for Trusted Platform Module.
require to insert a TPM module to the TPM port.
Enable/Disable TPM
TCG (TPM 1.1/1.2)
support
in BIOS
Execute TPM Command
Disabled
Enabled
Enable or Disable access to TPM command from
Operating System.
Enable(Activate)/
Disable(Deactivate)
Command to TPM
Clearing the TPM
[Press Enter]
Enter
Clear the TPM to Factory values. This will
remove password and other information saved
in the TPM.
TPM Enable/Disable Status N/A
Display the current configuration status of the
TPM.
Display the current
status of the TPM.
TPM Owner Status N/A
Display the current configuration status of the
TPM.
Display the current
status of the TPM.
