4.3.3.4 AMC Point-To-Point Connectivity Information
The following table gives AMC connectivity details for "Intel IOH PCI-Express Root Complex Port 3" (On-
Carrier Device 0).
Table 4-26:AMC connectivity details for "Intel IOH PCI-Express Root Complex Port 3"
Remote Port (Bit 12-8) 2h
Remote Resource ID (Bits 7-0)
00h ->Carrier, Device 0
(Intel IOH PCI-Express Root Complex Port 3)
Point-to-Point Port Descriptor 00e300h
Reserved (Bits 23-18) 0h
Local Port (Bits 13-17) 7h
Remote Port (Bit 12-8) 3h
Remote Resource ID (Bits 7-0)
00h ->Carrier, Device 0
(Intel IOH PCI-Express Root Complex Port 3)
Point-to-Point Port Descriptor 018102h
Reserved (Bits 23-18) 0h
Local Port (Bits 13-17) Ch
Remote Port (Bit 12-8) 1h
Remote Resource ID (Bits 7-0)
02h ->Carrier, Device 2
(Intel ICH SATA Controller)
Point-to-Point Port Descriptor 01a006h
Reserved (Bits 23-18) 0h
Local Port (Bits 13-17) Dh
Remote Port (Bit 12-8) 0h
Remote Resource ID (Bits 7-0)
06h ->Carrier, Device 6
(FPGA Based UART)
Point-to-Point Port Descriptor 01af85h
Reserved (Bits 23-18) 0h
Local Port (Bits 13-17) Dh
Remote Port (Bit 12-8) Fh
Remote Resource ID (Bits 7-0) 85h ->AMC Site 5 (AMC B1)
Field Value
Record Type ID C0h
Record format version 02h
Record Length *Calculated
Record Checksum *Calculated
Header Checksum *Calculated
Manufacturer ID 00315Ah
PICMG Record ID 19h (AMC Point-To-Point Connectivity Record)
Record Format Version 00h
Field Value
