B-7

AT8050

www.kontron.com

B.11 Power (P10)

Signal

Pin

Pin

Signal

N.P.

1

2

N.P.

N.P.

3

4

N.P.

HA0

5

6

HA1

HA2

7

8

HA3

HA4

9

10

HA5

HA6

11

12

HA7/P

SCL_A

13

14

SDA_A

SCL_B

15

16

SDA_B

MT1_TIP(N.C.)

17

18

MT2_TIP(N.C.)

RING_A(N.C.)

19

20

RING_B(N.C.)

MT1_RING(N.C.)

21

22

MT2_RING(N.C.)

RRTN_A(N.C.)

23

24

RRTN_B(N.C.)

SHELF_GND

25

26

LOGIC_GND

ENABLE_B

27

28

VRTN_A

VRTN_B

29

30

EARLY_A

EARLY_B

31

32

ENABLE_A

-48V_A

33

34

-48V_B
