Page 74
58
www.kontron.com
4.3.3
FRU Information
Table 4-19:Board Information Area
75
CPU Status
76
Bios Flash 0
77
Bios Flash 1
79
IPMI Watchdog
Board Information Area
Field Description
Value (hex)
Format Version
0x01
Board Area Length
*Calculated
Language code
0x19
Manufacturing Date /
Time
*Based on mfg. date
Board Manufacturer
type/length
*Calculated
Board Manufacturer
"KONTRON "
Board Name type/length
*Calculated
Board Name
“AT8050”
Board Serial Number
type/length
*Calculated
Board Serial Number
*10 digits serial number
Board Part Number
type/length
*Calculated
Board Part Number
T5007AA#_R-ZZZZZ
(R= Board revision)
(Z=config. 00000 = No DDR3, 00001 = 12GB DDR3)
FRU File ID type/length
*Calculated
FRU File ID
“FRU5007-XX"
(XX=template version)
No more fields
0xC1
Padding
None
Board Area Checksum
*Calculated
IPMI sensor ID
Sensor Name
