B. connector pinouts, B.1 connectors and headers summary, B.2 post codes (j2) – Kontron AT8050 User Manual
Page 147
B-1
www.kontron.com
B. Connector Pinouts
B.1
Connectors and Headers Summary
B.2
Post Codes (J2)
Connector
Description
J2
PostCodes
J5
AMC
J8
Ethernet Port 0
J9
Ethernet Port 1
J10
USB (2x Stacked)
J12
Serial Port, COM1
J20
Synchronisation Clocks, Update Channel
J22
USB Flash Drive
J23
Base Interface & Fabric Intercface
J30
RTM
P10
Power & IPMB
Signal
Pin
VCC3
1
POST:DATA
2
POST:CLOCK
3
GND
4
