Local Port (Bits 13-17) 5h
Remote Port (Bit 12-8) 1h
Remote Resource ID (Bits 7-0)
01h ->Carrier, Device 1
(Intel IOH PCI-Express Root Complex Port 7)
Point-to-Point Port Descriptor 00c201h
Reserved (Bits 23-18) 0h
Local Port (Bits 13-17) 6h
Remote Port (Bit 12-8) 2h
Remote Resource ID (Bits 7-0)
01h ->Carrier, Device 1
(Intel IOH PCI-Express Root Complex Port 7)
Point-to-Point Port Descriptor 00e301h
Reserved (Bits 23-18) 0h
Local Port (Bits 13-17) 7h
Remote Port (Bit 12-8) 3h
Remote Resource ID (Bits 7-0)
01h ->Carrier, Device 1
(Intel IOH PCI-Express Root Complex Port 7)
Point-to-Point Port Descriptor 010804h
Reserved (Bits 23-18) 0h
Local Port (Bits 13-17) 8h
Remote Port (Bit 12-8) 8h
Remote Resource ID (Bits 7-0)
04h ->Carrier, Device 4
(Fabric Channel 1 via OnBoard Switch)
Point-to-Point Port Descriptor 012805h
Reserved (Bits 23-18) 0h
Local Port (Bits 13-17) 9h
Remote Port (Bit 12-8) 8h
Remote Resource ID (Bits 7-0)
05h ->Carrier, Device 5
(Fabric Channel 2 via OnBoard Switch)
Point-to-Point Port Descriptor 014704h
Reserved (Bits 23-18) 0h
Local Port (Bits 13-17) Ah
Remote Port (Bit 12-8) 0h
Remote Resource ID (Bits 7-0)
04h ->Carrier, Device 4
(Fabric Channel 1 via OnBoard Switch)
Point-to-Point Port Descriptor 016705h
Reserved (Bits 23-18) 0h
Local Port (Bits 13-17) Bh
Remote Port (Bit 12-8) 7h
Remote Resource ID (Bits 7-0)
05h ->Carrier, Device 5
(Fabric Channel 2 via OnBoard Switch)
Point-to-Point Port Descriptor 01ed07h
Reserved (Bits 23-18) 0h
Local Port (Bits 13-17) Fh
Remote Port (Bit 12-8) Dh
Field Value
