4.3.2.1
IPMC Sensors
Table 4-17: IPMC Sensors
ID
Sensor Name
Sensor Class
Description (Sensor Type, Event trigger)
0
FRU0 Hot Swap
Discrete
ATCA Board FRU Hot Swap Sensor for FRU 0 (Front Board)
Sensor type code = F0h PICMG Hot Swap
Event Reading type code = 6Fh Sensor specific
See PICMG 3.0 R3.0 Table 3-22, “FRU Hot Swap event message”
1
FRU1 Hot Swap
Discrete
ATCA Board FRU Hot Swap Sensor for FRU 1 (AMC B1)
Sensor type code = F0h PICMG Hot Swap
Event Reading type code = 6Fh Sensor specific
See PICMG 3.0 R3.0 Table 3-22, “FRU Hot Swap event message”
2
FRU2 Hot Swap
Discrete
ATCA Board FRU Hot Swap Sensor for FRU 2 (RTM)
Sensor type code = F0h PICMG Hot Swap
Event Reading type code = 6Fh Sensor specific
See PICMG 3.0 R3.0 Table 3-22, “FRU Hot Swap event message”
3
FRU3 Hot Swap
Discrete
ATCA Board FRU Hot Swap Sensor for FRU 3 (RTM Disk)
Sensor type code = F0h PICMG Hot Swap
Event Reading type code = 6Fh Sensor specific
See PICMG 3.0 R3.0 Table 3-22, “FRU Hot Swap event message”
4
FRU0 Reconfig
Discrete
Sensor Population Change on Carrier
Sensor type = 12h System Event
Event Reading type code = 6Fh Sensor specific, only offset 0 is used -see AMC.0
R2.0 for event trigger
-see IPMI v1.5 table 36.3, Sensor type code 12h for sensor definition
5
Temp -48V A Feed
Threshold
DC Feed A Input Temperature (Degrees)
Sensor type = 01h temperature
Event Reading type code = 01h threshold based
see IPMI v1.5 section 29.13.3 for threshold based event
6
Temp -48V B Feed
Threshold
DC Feed B Input Temperature (Degrees)
Sensor type = 01h temperature
Event Reading type code = 01h threshold based
see IPMI v1.5 section 29.13.3 for threshold based event
7
Temp Mez 12V Out
Threshold
DC Feed 12V Out Temperature (Degrees)
Sensor type = 01h temperature
Event Reading type code = 01h threshold based
see IPMI v1.5 section 29.13.3 for threshold based event
8
Temp VDDQ
Threshold
VDDQ Temperature (Degrees)
Sensor type = 01h temperature
Event Reading type code = 01h threshold based
see IPMI v1.5 section 29.13.3 for threshold based event
9
Temp Vcore
Threshold
Vcore Switcher Temperature (Degrees)
Sensor type = 01h temperature
Event Reading type code = 01h threshold based
see IPMI v1.5 section 29.13.3 for threshold based event
10
Temp IPMC
Threshold
H8S2472 IPM Controller Temperature (Degrees)
Sensor type = 01h temperature
Event Reading type code = 01h threshold based
see IPMI v1.5 section 29.13.3 for threshold based event
11
Temp IOH
Threshold
I/O Hub (IOH) Chipset Temperature (Degrees)
Sensor type = 01h temperature
Event Reading type code = 01h threshold based
see IPMI v1.5 section 29.13.3 for threshold based event
