Arc Machines 207 - Manual (Page 75)

MODEL 207A AND 207A-1
OPERATION MANUAL
Doc. No. 740044
Rev F
SECTION VIII - OPTIONS
8.2 M-207-RP REMOTE PENDANT
2. Operation (continued)
4. As previously noted, the M-207A can store in memory up to 100 weld
schedules. Any 4 of these schedules can be programmed to be selected
from the RP. The Weld # key is used to select one of these 4 weld
schedules.
To initially set up which schedules can be selected from the M-207-RP
press the SET UP key on the M-207A (this operation cannot be done from
the RP). The SET UP screen can be obtained from the STATUS screen or
a Weld Schedule screen.
Press the F key under WELD SELECT and the screen will then ask what
WELD # should be in position 1, then position 2, 3 and 4. You do not
have to select all 4, just the ones you want selectable from the M207-RP.
When all choices (up to 4) are made, go back to the STATUS screen.
The M-207-RP will now be able to select one of the Weld #’s entered.
Press the Weld # key to select the first of the selected schedules. The first
weld the first of the selected schedules. The first Weld # number will be
displayed. Each time the key is pressed the next Weld # selected will be
displayed.
5. The Amps Up and Amps Down keys are used to Override the PRIMARY
CURRENT before welding. They do not work during Sequence and they
do not change Background. The first actuation of either key enables the
function and displays the value of Level 1 Primary Amps. The next time
either key is pressed the value will change (up or down) by the smallest
increment (usually 1 amp).
Each time either key is pressed the current will be changed by one
increment.
The same amount of change will be made to all Levels of Primary Amps.
The amount of change that can be made will be controlled by the Override
limits programmed and the percentage will be based on the smallest value
of Primary Amps in any level.
8.5
