Arc Machines 207 - Manual (Page 15)

MODEL 207A AND 207A-1
OPERATION MANUAL
Doc. No. 740044
Rev F
SECTION II - SPECIFICATIONS
2.0 ELECTRICAL
4. CIRCUIT BREAKER - ON/OFF, two pole, 30 Ampere at 250 VAC.
2.1
PHYSICAL CONSTRUCTION - (power supply only)
Cabinet material - aluminum
Height - 10.9 in (276.9 mm) cover closed
- 9.3 in (236.2 mm) cover removed
Width - 22.75 in (577.9 mm)
Depth - 19.25 in (489.0 mm) including handle
Weight - 78 lbs (35.4 kg) (M-207A and M-207A-1)
2.2 PROGRAMMABLE and OPERATIONAL FUNCTIONS
PREPURGE TIME ............................................... = 010 - 999 seconds
POSTPURGE TIME ........................................... = 000 - 999 seconds
UPSLOPE TIME .................................................. = 00.0 - 99.9 seconds
DOWNSLOPE TIME .......................................... = 00.0 - 99.9 seconds
ROTATION START DELAY ............................. = 00.0 - 99.9 seconds
ROTATION MODE SETTINGS ........................ = CONT - STEP - OFF
PRIMARY ROTATION SPEED ........................ = 0.00 - 20.0 RPM
BACKGROUND ROTATION SPEED .............. = 0.00 - 20.0 RPM
PULSE MODE SETTINGS ................................ = ON - OFF
PRIMARY PULSE TIME ................................... = 0.00 - 9.99 seconds
BACKGROUND PULSE TIME .......................... = 0.00 - 9.99 seconds
LEVELS .............................................................. = 1 - 99
LEVEL TIME (each level) ................................... = 000 - 999 seconds*
PRIMARY CURRENT ........................................ = 3 - 150 amperes*
BACKGROUND CURRENT .............................. = 3 - 150 amperes*
* = Can be in increments of 0.1
2.3
MULTI-LEVEL FUNCTIONS - The following functions can be programmed to
change value during a given weld sequence.
FUNCTION POSSIBLE CHANGES
LEVEL TIME ...................................................... = 1 to 99 levels
2.3
