MODEL 207A AND 207A-1
OPERATION MANUAL
Doc. No. 740044
Rev F
SECTION VI - PROGRAMMING
6.2 MODIFY A WELD SCHEDULE
2. Modifying a weld schedule works similar to reviewing a weld schedule in the
operate mode (see section V). Use the NEXT/PREV SCREEN and
NEXT/PREV LEVEL keys to find the function and level to be modified.
3. When the function value or mode to be modified is found use the F key above
or below it to enable it to be modified. Use the numeric keys to enter the new
value, for changes of mode use the F key again.
Verify the correct change and then press the ENTER key. If more changes are
needed, find the next item with SCREEN and LEVEL keys and use the same
method to modify it.
To DELETE a LEVEL use the NEXT/PREV keys to find the Level Time for
the Level to be deleted. Enter 0 time to DELETE the LEVEL. All subsequent
Levels will advance one number.
When all items have been modified press the PRO key. The system will ask if
you want to STORE or continue MODIFYING. Remember, NONE OF THE
CHANGES MADE ARE ENTERED INTO MEMORY UNTIL THEY ARE
STORED.
6.3
COPY A WELD SCHEDULE
To COPY a weld schedule you must start from the STATUS screen and the
OPERATE mode switch must be in the PROGRAM position.
1. Press the PRO key. Then use the appropriate F key to select COPY and then
press the ENTER key.
2. The screen will then ask you what weld schedule number you wish to COPY.
Use the numeric keys, verify and then press the ENTER key. The system will
then ask you what the weld schedule number should be for the COPY. Use
the numeric keys, verify and the press the ENTER key.
3. The system will then proceed to COPY the weld schedule. When it is copied
the program screen will appear and MODIFY can be selected to modify the
COPIED weld schedule.
6.5
