MODEL 207A AND 207A-1
OPERATION MANUAL
Doc. No. 740044
Rev F
SECTION VIII - OPTIONS
8.1 M227/207-CW & M207-CW COOLING UNIT SPECIFICATIONS/INSTALLATION
5. Operation -
2. Both M227/207-CW & M207-CW contain flow sensors. Any time the CW
unit is turned ON a signal will be sent to the M-207A that indicates if the
flow is adequate If it is the M-207 STATUS screen (at power up) displays
COOL-OK. If it is not OK the screen will display COOL-FLT. Any time
there is a COOL-FLT the problem must be corrected in order to weld.
3. If coolant is not needed, turning the CW unit OFF will disconnect the fault
function. THE COOLANT FAULT ONLY WORKS IF THE CW IS
TURNED ON.
4. The above is the basic operation. The only decision to be made is whether
COOLANT is required. Some weld heads need it, some do not, depending
on the type of weld and duty cycle. Consult with an AMI representative as
to cooling requirements.
8.2 M-207-RP REMOTE PENDANT
WARNING
Always turn the power supply OFF before making any cable or connection changes
to the M-207A power supply.
1. Installation
1. Insert the M-207-RP cable connector into the M-207A panel connector
labeled REMOTE.
2. If a M-207-RP extension is used, it is installed between the M-207A and the
M-207-RP.
2. Operation
NOTE
A complete understanding of system operation is necessary for proper use of
the RP. Section IV and section V of this manual must be read and understood
before proceeding with RP operation.
8.3
