MODEL 207A AND 207A-1
OPERATION MANUAL
Doc. No. 740044
Rev F
SECTION V - OPERATION
5.11 PRINTER OPERATION
4. (continued)
2. LIBRARY SCREEN - When the LIB key is pressed and any of the library
screens are being displayed a copy of the description of ALL WELD
SCHEDULES in memory can be printed. This print out will include each
WELD SCHEDULE NUMBER, OD, WALL, TYPE, MATERIAL,
QUANTITY of the welds performed and the DATE. At the bottom of the
print out will be the total QUANTITY of welds performed by the system.
3. INDIVIDUAL WELD SCHEDULE - When a weld schedule has been
selected from memory a complete copy of all of the function values can be
printed by pressing the PRINT key. This can be done at any time any
portion of a weld schedule is being displayed EXCEPT during an ACTUAL
WELD SEQUENCE.
A statement at the bottom of the print out will show whether ALL
PARAMETERS PERFORMED AS PROGRAMMED the last time the
weld was used. If the PRINT key is pressed after each weld is made, a
hard copy record of performance can be kept. The DATE is also included
on each print out. If Operator ID has been programmed (see SET UP) the
Operators name or ID will be printed. If WELD ID has been selected the
WELD ID will also be printed.
5. An auto-print function can also be set up to have the system automatically
make a print out after each Weld Sequence (in Weld Mode). If this mode is
selected the printer will automatically print out a copy of the complete weld
schedule after the first weld sequence. After each sequence (without changing
weld #) the printer will print the Library Description, Date and the “All
Parameters performed as programmed” statement.
6. There is another print function contained on the Set-Up Screen. This function
is to print a copy of the LIBRARY in the memory of the Optional M207-
EMM unit. See SET UP for further information.
5.17
