MODEL 207A AND 207A-1

OPERATION MANUAL

Doc. No. 740044
Rev F

SECTION V - OPERATION

5.7

SET UP FUNCTIONS

1. SET UP FUNCTIONS IN OPERATE MODE

HEAD CAL - This feature is used to calibrate Travel (rotation) speed of

the Weld Heads and MUST BE USED ANY TIME A CHANGE OF

WELD HEADS IS MADE. See Section 5.7 for operation.

REV - Pressing the F key under this will show the current software

REVISION installed. This can be important when discussing problems

or features with an AMI representative.

NOTE

The following are on the second SET UP screen and are accessed by pressing

NEXT SCREEN from the first SET UP screen.

PRINT EMM - Pressing the F key under this choice will create a Print

out of the LIBRARY contained in M-207-EMM Option (EMM must be

installed, see 8.3).

AMP - TIME - This feature allows the user to change the programmable

increments of LEVEL AMPS or LEVEL TIME from 000 (whole

numbers) to 000.0 (tenths).

NOTE

This is not on an individual WELD # basis. All WELD # will be

changed automatically. If a WELD # was originally programmed for

87.7 amperes and this is changed to whole numbers the WELD # when

accessed will then call for 87 amperes (it will drop the digit, not round

off).

7. ARC V FAULT - This feature can turn this FAULT ON or OFF. When

ON a STUB OUT will be created if the ARC VOLTAGE goes below 5V

or a HIGH VOLTS fault if the VOLTAGE goes over 20 V. However, in

manual welding these conditions can occur without anything being

wrong. THIS FEATURE NEEDS TO BE SET TO OFF FOR

MANUAL WELDING.

NOTE

The following are on the third SET UP screen (in operate mode) and are

accessed by pressing NEXT SCREEN from the second SET UP screen.

5.8
