MODEL 207A AND 207A-1
OPERATION MANUAL
Doc. No. 740044
Rev F
SECTION IV - SYSTEM FUNCTIONS
4.9
GLOSSARY OF DISPLAY SYMBOLS AND ABBREVIATIONS - The M-207A
displays contain many abbreviations. The following is an alphabetical listing
(symbols last) of most abbreviations.
AL
= Aluminum
AMP
= Amperage
AF
= Automatic weld fitting
BCK
= Background (low value of a function that pulses).
CAL
= Calibrate or calibration
CCW
= Counterclockwise - looking at M-9 from COVER SIDE.
CONT = Continuous (constant value, no pulsing)
COOL = Coolant flow
CS
= Carbon steel
CW
= Clockwise - looking at M-9 from COVER SIDE.
DLY
= Delay time
EXT
= External input or function
FLT
= Fault
FTG
= Fitting other than AF
HAS
= Hastaloy
INC
= Inconel
INPUTAC = In put power AC voltage check
IPM = Inches per minute
LIB = Library, listing of programmed weld schedules
LVL = Level or levels
LVPS = Low voltage DC power supply check
MAT = Material
MNL = Monel
OD = Outside diameter
OK = Means monitored function is operating properly.
PRE-PURGE-POST = Prepurge, postpurge columns.
PRI = Primary function value
PRI-AMP-BCK = Primary speed, background amp columns
PRI-PULSE-BCK = Primary time, background speed columns
PRI-RPM-BCK = Primary speed, background speed columns
PRO = Program mode
QTY = Quantity of weld made since last reset
QTY RESET = Select to reset weld quantity
REV = Software revision
ROT = Rotation or travel start delay time
4.15
