Specifications
Video camera " ”
recorder
System
Video recording system
Two rotary heads. Helical
scanning system
Audio recording system
Rotary heads, PCM system
Quantization: 12bits (Fs 32kHz,
stereo 1, stereo 2), 16bits (Fs
4HkHz, stereo)
Video signal
NTSC color, EIA standards
Usable cassette
Mini DV cassette with logo
printed
Recording/playback time
SP mode: 1 hour (DVM60)
LP mode: 1.5 hours (DVM60)
Fastforward/rewind time
Approx. 3 min. 30 s (DVM60)
Viewfinder
Electric viewfinder (color)
Image device
CCD (Charge Coupled Device
1/4")
Lens
Combined power zoom lens (Carl
Zeiss), 120x (Digital), lOx (Optical)
Focal distance
f = 3.3 to 33 mm
(42 to 420 mm when converted
into a 35 mm still camera)
Fl.7-2.2
Color temperature
Auto
HOl.D, INDOOR 3,200K,
OUTDOOR 5,800K
Minimum illumination
5 lux at F 1.7
Illumination range
5 to 100,000 lux^
Recommended illumination
More than 100 lux
LCD screen
2.5 inches measured diagonally
2x1 1/2 inches (50.015 x 37.428
mm)
On-screen display
TN iXD/TFT active matrix
method
Total dot number
180,iXX) (800x225)
Input and output ^
connectors
S video output
4-pin mini DIN
Luminance signal: 1 Vp-p, 75
ohms, unbalanced, sync negative
Chrominance signal: 0.286 Vp-p,
75 ohms, unbalanced
Audio Video/Headphones
output
Special minijack
V: 1 Vp-p, 75 ohms, unbalanced,
sync negative
A: 327 mV (at output impedance
more than 47 kilohms)
Output impedance with less than
2.2 kilohms/Headphones:
Stereominijack (e 3.5 mm)
' DV input/output
4-pin connector
MIC input
Stereo minijack (e 3.5mm):
0.388m V, DC2.5V
Input impedance 6.8 kilohms
CLANCjack
Stereo miniminijack (0 2.5 mm)
General
Power requirements
3.6 V (battery insertion input)
Average power consumption
3.2 W during camera recording
using viewfinder
4.5 W during camera recording
using LCD screen
Operating temperature
32“F to 104“F (0“C to 40X)
Storage temperature
-4“F to 140^F (-20X to 60X)
Dimensions
Approx. 21/8x43/4x33/4
inches (52 x 119 x 92.5 mm)
(w/h/d) excluding projecting
parts
Mass
Approx. 1 lb. (460 g) excluding the
battery pack and the cassette
Approx. 1 lb. 2 oz. (530 g)
including the battery pack NP-FIO
and cassette DVM60
Microphone
Electret condenser microphone.
Stereo type
Speaker
Dynamic speaker
Supplied accessories
See page 6.
Power requirements
100 to 240 V AC, 50/60 Hz
Power consumption
4.2 W
Output voltage
DC OUT: 4.2 V, 1.8 A in operating
mode
Battery charge terminal: 4.2 V, 1.5
A in charge mode
Application
Sony battery pack NP-FlO,
NP-F20, NP-F30 lithium ion type
Operating temperature
32®Ftol04T (OX to40“C)
Storage temperature
to \4ir? (-20X to 60“C)
Dimensions
Approx. 115/16 X1 9/16 X 3 3/8
inches (49
X 39 X 85 mm) (w/h/d)
Mass
Approx. 4.2 oz. (120 g)
Design and specifications are
subject to change without notice.
