Photo recording
A; .
You can print a still picture by using the video printer (not supplied). Connect the video
printer using the supplied A/V connecting cable.
Connect it to the AUDIO VIDEO OUT/0 jack and connect the yellow plug of the cable
to the video input of the video printer. Refer to the operating instructions of the video
printer as well.
AUDIO VIDEO OUT/0
Signal flow
If the video printer is equipped with S video input
Use the S video connecting cable (not supplied). Connect it to the S VIDEO OUT jack
and the S video input of the video printer.
