Figure 15. Front-panel features and indicators — 3.5 inch hard drive chassis
Item Indicator, Button, or
Connector
Icon Description
1 USB connectors (2) Allows a keyboard and mouse to be connected to
the system.
2 LCD panel Provides system information and status and error
messages to indicate when the system is operating
correctly or when the system needs attention.
3 LCD menu scroll buttons
(4) Moves the cursor in one-step increments.
4 Selection ("check") button Selects and saves an item on the LCD screen and
moves to the next screen.
5 Enclosure power-on
indicator, power button The power-on indicator lights when the enclosure
power is on. The power button controls the power
supply output to the system.
6 Hard drives
2.5 inch hard
drive enclosure Up to twenty five 2.5 inch
hot-swappable hard
drives.
19
