Chassis Status Server Module Status Expansion Card Status
On Off Off
On On Off
NOTE: The system cover must be
installed for the new expansion
card to power on.
NOTE: To verify if a PCIe slot is powered on, see PCIe Slot Indicators .
PCIe slot indicators
The expansion-card slots are warm-plug. A PCIe card has to be prepared for removal from a system that is turned on,
using the CMC. The PCIe slot indicators show that a PCIe card is ready for removal.
Figure 58. PCIe slot indicators
1. PCIe slot indicators for low-profile expansion cards 2. PCIe slot indicators for full-height expansion cards
The PCIe slot indicators provide the following information:
Indicator Description
Slot power indicator
Steady Green The slot is receiving power.
Blinking Green Warm-plug operation is in progress and insertion or removal of the
adapter is not allowed.
Off Power supply to the slot is off, and the expansion card can be
removed.
