Figure 25. Removing and installing the front bezel
1. release tab 2. keylock
3. front bezel 4. bezel tabs
Removing the front bezel
1. Insert the bezel key in the keylock.
2. Keeping the keylock pressed with the bezel key, rotate the keylock to the unlocked position.
3. Press the release tab at the top of the bezel toward the right.
4. Move the top end of the bezel away from the system.
5. Unhook the bezel tabs from the slots on the front of the chassis.
System feet—tower mode
The system feet provide stability to the system in the tower mode.
Removing the system feet
1. To reduce the chassis weight, remove the following (if required):
a. Front bezel (if installed)
b. Hard drives. See
Removing A Hot-Swap Hard Drive .
c. Server modules. See Removing A Server Module .
d. Power supplies. See Removing A Power Supply .
2. Rotate the system feet inward.
3. Lay the enclosure on its side on a flat, stable surface with the cover release latch side on top.
4. Remove the screws securing the system feet to the system base cover.
