Storage controller operational power status
The following table provides information on the operational power status of the integrated storage controller card when:
• the storage controller slot is mapped to multiple server modules
• the system cover is installed
Chassis Status Server Module Status (All Server
Modules)
Storage Controller Status
Off Off Off
Standby Off Off
On Off or On
• On — The status of the integrated storage
controller card installed in storage
controller slot 1, labelled as
INT_STORAGE_1 on the system board.
• Off — The status of the integrated storage
controller card slot 2, labelled as
INT_STORAGE_2 on the system board, in a
single storage controller configuration.
The following table provides information on the operational power status of a storage controller when:
• the storage controller card is replaced in the storage controller slot
• the system cover is removed
Chassis Status Server Module Status (All Server
Modules)
Storage Controller Status
On Off Off
On On Off
NOTE: The system cover must be installed
for the new storage controller to power
on.
NOTE: To verify if the storage controller is powered on, see Storage Controller Card Indicators .
